Spectrogon宽带通滤光片
Broad Bandpass Filters
Spectral measurements
Spectral curve at room temperature and normal incidence angle is supplied with each filter type.
Description: BBP-HP1-HP2 in nanometers (HP 50 % of Tpeak)
(Ex BBP-0555-0695c nm, c stands for that the filter is classified after Cuton and Cutoff 5 %, instead of HP1 and HP2 50 % as normal)
Spectrogon宽带通滤光片
General Specifications
Diameter: 25.4 mm +0/-0.2 mm. Custom sizing
Thickness: Specified in the filter list below （mm）, tol ±0.2 mm
Blocking: Avg < 0.1 % UV to block high
Slope: < 5 %
|
Description |
Substrate |
Thk |
HP1 50 % |
HP2 50 % |
Transm |
Block high |
|
BBP-0910-1170c nm |
Glass |
.50 |
30,00 |
30,00 |
70,00 |
2000,00 |
|
BBP-1500-1900 nm |
Glass |
.50 |
75,00 |
75,00 |
75,00 |
3500,00 |
|
BBP-1500-4200 nm |
Silicon |
1.00 |
100,00 |
100,00 |
70,00 |
6500,00 |
|
BBP-1530-1730 nm |
Glass |
.50 |
50,00 |
50,00 |
55,00 |
2500,00 |
|
BBP-1615-2280 nm |
Silicon |
.50 |
50,00 |
50,00 |
70,00 |
3500,00 |
|
BBP-1800-2200 nm |
Glass |
.50 |
50,00 |
50,00 |
65,00 |
3500,00 |
|
BBP-2050-2600 nm |
Glass |
.50 |
100,00 |
100,00 |
80,00 |
3500,00 |
|
BBP-2200-2600 nm |
Glass |
.50 |
50,00 |
50,00 |
70,00 |
30000,00 |
|
BBP-2850-3850 nm |
Sapphire |
.50 |
75,00 |
75,00 |
70,00 |
30000,00 |
|
BBP-2900-3810 nm |
Quartz |
.50 |
75,00 |
75,00 |
70,00 |
30000,00 |
|
BBP-2960-3260 nm |
Quartz |
1.00 |
75,00 |
75,00 |
70,00 |
5500,00 |
|
BBP-3040-4500 nm |
Sapphire |
.50 |
50,00 |
50,00 |
70,00 |
30000,00 |
|
BBP-3190-3840c nm |
Quartz |
1.00 |
75,00 |
75,00 |
70,00 |
30000,00 |
|
BBP-3300-3750 nm |
Quartz |
.55 |
100,00 |
100,00 |
70,00 |
30000,00 |
|
BBP-3370-4075 nm |
Sapphire |
1.00 |
50,00 |
50,00 |
70,00 |
30000,00 |
|
BBP-3400-4000 nm |
Silicon |
.55 |
100,00 |
100,00 |
70,00 |
18000,00 |
|
BBP-3440-4075 nm |
Sapphire |
1.00 |
50,00 |
50,00 |
70,00 |
30000,00 |
|
BBP-3485-5200c nm |
Ge |
1.00 |
100,00 |
125,00 |
80,00 |
6000,00 |
|
BBP-3500-5000 nm |
Silicon |
.50 |
100,00 |
100,00 |
70,00 |
10500,00 |
|
BBP-3550-5150 nm |
Ge |
1.00 |
100,00 |
125,00 |
80,00 |
10500,00 |
|
BBP-3670-4020 nm |
Sapphire |
1.00 |
100,00 |
100,00 |
70,00 |
30000,00 |
|
BBP-3700-4200 nm |
Sapphire |
1.00 |
100,00 |
100,00 |
70,00 |
30000,00 |
|
BBP-3725-4245 nm |
Sapphire |
1.00 |
75,00 |
85,00 |
70,00 |
6000,00 |
|
BBP-3800-5050 nm |
Ge |
.50 |
150,00 |
150,00 |
80,00 |
7500,00 |
|
BBP-4000-5000 nm |
Sapphire |
1.00 |
100,00 |
150,00 |
80,00 |
30000,00 |
|
BBP-4150-4620 nm |
Sapphire |
.50 |
100,00 |
100,00 |
70,00 |
30000,00 |
|
BBP-4170-4790 nm |
Sapphire |
1.00 |
100,00 |
100,00 |
70,00 |
30000,00 |
|
BBP-4205-5015c nm |
Sapphire |
1.00 |
70,00 |
70,00 |
70,00 |
6000,00 |
|
BBP-4400-4900 nm |
Silicon |
.50 |
150,00 |
150,00 |
70,00 |
5500,00 |
|
BBP-5020-5570c nm |
Sapphire |
.50 |
100,00 |
100,00 |
70,00 |
30000,00 |
|
BBP-5020-5706 nm |
Sapphire |
.50 |
100,00 |
100,00 |
70,00 |
30000,00 |
|
BBP-5025-5700c nm |
Sapphire |
.50 |
75,00 |
75,00 |
70,00 |
30000,00 |
|
BBP-5030-5730c nm |
Sapphire |
.50 |
75,00 |
75,00 |
70,00 |
30000,00 |
|
BBP-5040-5595c nm |
Ge |
1.00 |
100,00 |
100,00 |
70,00 |
30000,00 |
|
BBP-5040-5715c nm |
Sapphire |
.50 |
75,00 |
75,00 |
70,00 |
30000,00 |
|
BBP-5050-5675c nm |
Sapphire |
.50 |
100,00 |
100,00 |
70,00 |
30000,00 |
|
BBP-5120-5765c nm |
Ge |
1.00 |
100,00 |
100,00 |
70,00 |
8500,00 |
|
BBP-5500-6000 nm |
Silicon |
1.00 |
100,00 |
100,00 |
70,00 |
14000,00 |
|
BBP-7000-8750c nm |
Ge |
1.00 |
200,00 |
200,00 |
80,00 |
12000,00 |
|
BBP-7795-10680 nm |
Ge |
1.00 |
200,00 |
200,00 |
70,00 |
15000,00 |
|
BBP-7950-9300 nm |
Ge |
1.00 |
150,00 |
150,00 |
60,00 |
20000,00 |
|
BBP-8075-9400 nm |
Ge |
1.00 |
150,00 |
150,00 |
70,00 |
20000,00 |
|
BBP-8075-9400 nm |
Ge |
1.00 |
150,00 |
150,00 |
70,00 |
20000,00 |
|
BBP-8170-10695c nm |
Ge |
1.00 |
200,00 |
200,00 |
70,00 |
15000,00 |
|
BBP-8235-10750c nm |
Ge |
1.00 |
250,00 |
250,00 |
70,00 |
15000,00 |
|
BBP-8250-8760 nm |
Ge |
1.00 |
50,00 |
50,00 |
70,00 |
12000,00 |
|
BBP-8500-15800 nm |
Ge |
.50 |
350,00 |
350,00 |
70,00 |
23000,00 |
|
BBP-8900-13250 nm |
ZnS |
1.40 |
150,00 |
150,00 |
70,00 |
20000,00 |
|
BBP-8925-9275 nm |
Ge |
1.00 |
150,00 |
150,00 |
70,00 |
12000,00 |
|
BBP-9040-9360 nm |
Ge |
1.00 |
100,00 |
100,00 |
70,00 |
12000,00 |
|
BBP-9100-9455 nm |
Ge |
1.00 |
100,00 |
100,00 |
70,00 |
12000,00 |
|
BBP-10000-11230 nm |
Silicon |
.50 |
250,00 |
250,00 |
70,00 |
20000,00 |
|
BBP-10300-12500 nm |
Ge |
1.00 |
250,00 |
250,00 |
70,00 |
15000,00 |
